Advanced GPS Vehicle Tracker – Real-Time Location Monitoring Locator

Description

Material
Plastic, Metal

Product Attributes
Ordinary

Package Size
100*50*20(mm)

Product features:

• The product features a 3-proof design, ensuring it is waterproof, fireproof, and dustproof.
• The GSM four frequency system is globally compatible.
• It includes a high sensitivity GPS receiver chip.
• Equipped with a built-in GPS antenna that boasts high sensitivity and exceptional receiving performance.
• The design allows for high integration.
• The vehicle terminal is designed with dual built-in antennas (GSM, GPS).
• It has a built-in switching power supply with an ultra-wide voltage input range.
• A built-in vibration sensor that enables intelligent anti-theft for vehicles.
• Supports ACC detection and vehicle start alarm.
• An external relay can be connected for controlling vehicle fuel and power.
• A built-in backup battery is included to trigger alarms for illegal thread cutting.
• Compatible with serial communication for external equipment.

Functional features:

• Size: 90 *52*20（mm）
• GSM: 850/ 900/ 1800/ 1900 MHz
• GPRS: Class12，TCP/ IP built in GSM Module
• GPS: u-blox-7020
• Number of channels: 20 channels
• Tracking sensitivity: – 159dBm
• Acquisition sensitivity: – 144dbm
• Positioning time:
  • Hot start: < 1 sec (open sky)
  • Warm start: < 15 sec
  • Cold start: < 38 sec (open sky)
• Built in antenna: GSM four band antenna, GPS high gain antenna
• Built in battery: 450mah
• Power input range: 8-75 VDC
• LED indicator: 3 LED status indication: GPS blue, GSM green, power red

Main functions of the product:

1. Real time positioning: The device uses a four core precision positioning chip, and the accuracy is calculated in seconds. After the vehicle is stolen and robbed, the vehicle can be remotely controlled at any time, providing driving state (time, speed, direction, position, etc.) to assist the police in solving the case quickly.
2. Built in battery: Built in high-quality high-temperature, flame-proof and explosion-proof military polymer battery to prevent thieves from cutting the power cord. The product can still work for more than 7 hours.
3. Electronic fence: Draw an area on the platform map. When the vehicle goes beyond or enters its own area, the platform will have alarm information, which is suitable for vehicle anti-theft and company vehicle height management.
4. Track playback: On our platform, we can save 60 days’ vehicle records, which is convenient for playback, displaying speed, direction, and stop time during playback.
5. Vibration alarm: The built-in vibration sensor can set the vibration duration alarm by SMS to realize the intelligent anti-theft of vehicles.
6. Shift alarm: Send SMS to set the vehicle shift distance alarm, allowing real-time monitoring of the vehicle’s state within its own set range.
7. Power off alarm: When the thief unlawfully removes the device or cuts the power line, the device immediately sends an alarm message to your mobile phone or calls (can be set), ensuring the thief has no escape.
8. Intelligent power saving: When the vehicle is stationary, the device will automatically enter the state of built-in battery power supply, avoiding continuous power consumption of the vehicle battery and failure of ignition.

The Advanced GPS Vehicle Tracker is a cutting-edge solution designed to enhance security and provide real-time location monitoring for vehicles across a diverse range of applications. This versatile device is ideal for personal vehicles, commercial fleets, and logistics operations, making it suitable for various industries such as transportation, delivery services, and personal vehicle management.

Whether you are a fleet manager looking to optimize routes and track vehicle performance or a concerned vehicle owner wishing to safeguard your asset from theft, this tracker offers a reliable solution. Its compact design and robust features ensure seamless integration into different vehicle types, ranging from cars and trucks to motorcycles, providing peace of mind in a multitude of scenarios.

Key Features

The Advanced GPS Vehicle Tracker stands out due to its unique combination of advanced technology and practical features. It employs a high-sensitivity GPS receiver chip and a GSM four-frequency system, ensuring global compatibility and dependable tracking performance.

• The device’s built-in vibration sensor enables intelligent anti-theft measures.
• The electronic fence feature allows users to set geographical boundaries and receive alerts if their vehicle strays outside designated areas.
• With the ability to send SMS alerts for power disconnections and unauthorized movements, this product is designed to keep users informed and in control.

These competitive advantages make the Advanced GPS Vehicle Tracker a superior choice compared to alternative tracking solutions, as it not only provides real-time updates but also incorporates preventative measures to deter theft effectively.

Quality Assurance

Quality is paramount in the design and manufacturing of the Advanced GPS Vehicle Tracker. Constructed from durable plastic and metal materials, this device features a three-proof design that makes it waterproof, fireproof, and dustproof, ensuring reliable performance even in harsh environments.

The craftsmanship behind the product guarantees durability and longevity, while the built-in high-temperature and flame-proof military polymer battery provides additional security against tampering or power interruptions. With a performance range that includes a tracking sensitivity of -159dBm and a positioning time that facilitates quick location fixes, this device meets high standards of quality assurance.

The integration of a backup battery ensures that the tracker continues to function even if the main power supply is compromised, reinforcing its reliability and effectiveness in safeguarding your vehicle.

Bulk Purchase Options

For businesses and individuals interested in bulk purchases, the Advanced GPS Vehicle Tracker offers favorable pricing options, making it an economical choice for fleet management or personal use. Bulk orders can significantly reduce costs, allowing organizations to equip multiple vehicles with this essential monitoring tool at a competitive price.

We encourage potential bulk buyers to contact us for more information regarding pricing and availability. Our team is ready to assist with inquiries and provide additional details about the product’s features and benefits, ensuring you have the best solution for your tracking needs.

Don’t hesitate—reach out to us today to explore how the Advanced GPS Vehicle Tracker can enhance your vehicle security and monitoring capabilities.
