Description
Material
Plastic
Product Attributes
Ordinary
Package Size
180*230*40 (mm)
Use occasion:
Water towers, water heaters, fish tanks, fish ponds, pumping pumps, the sensor automatically stops pumping when reaching the sensor, or pumping beyond the water level, can control high-current equipment base stations, machine rooms, libraries, garages, warehouses, archives, and other important occasions. Normally open normally closed signal output.
Features:
When the water level exceeds the sensor, the relay will activate, causing the pump to either stop working or start functioning, featuring a normally open and normally closed switch; the relay will trigger, with normally open becoming closed and normally closed becoming open.
Good isolation:
The sensor is distinct from the controller, unaffected by water; it is resistant to interference, boasts high sensitivity, rapid response, and other attributes. High sensitivity: precise detection with no false alarms.
Electrical parameters:
- Working voltage: 10 to 15VDC (other working voltages can be customized)
- Working current: <100mA
- Load: 250V 10A AC or 30V 10A DC (lower than this range can be used)
The Advanced Water Level Sensor is designed to deliver accurate monitoring and control of water levels in various applications, making it an essential tool for a wide range of industries. This versatile sensor can be utilized effectively in settings such as water towers, water heaters, fish tanks, fish ponds, and pumping stations. It is engineered to automatically stop pumping when the water level reaches the sensor, thereby preventing overflow or dry running of pumps. The sensor’s functionality extends to critical locations such as base stations, machine rooms, libraries, garages, warehouses, and archives, where precise water level management is crucial. The ability to interface with high-current equipment, coupled with its normally open and normally closed signal output, makes this sensor an ideal solution for both residential and commercial applications that require reliable water level control.
One of the standout advantages of the Advanced Water Level Sensor is its high sensitivity and rapid response time, which allows for precise detection of water levels without the risk of false alarms. This feature significantly enhances the user experience, as it ensures that the system responds accurately to changing water levels. The sensor is designed with good isolation properties, ensuring that it remains unaffected by water interference. Additionally, its electrical parameters are adaptable, supporting a working voltage range of 10 to 15VDC, with customizable voltage options available. The sensor can handle loads of up to 250V at 10A AC or 30V at 10A DC, making it a robust choice for various applications. These competitive advantages position the Advanced Water Level Sensor as a superior choice over alternative products in the market, ensuring customers receive both reliability and performance.
Quality is at the forefront of the Advanced Water Level Sensor’s design, crafted from durable plastic materials that promise longevity and resilience in diverse environments. The craftsmanship involved in producing this sensor guarantees high reliability, essential for applications where water level monitoring is critical. Its robust construction is complemented by stringent quality assurance measures, ensuring it meets high standards of performance and durability. Users can trust that the sensor will maintain its functionality over time, providing consistent and accurate monitoring that is crucial for effective water management. The combination of quality materials and meticulous design reflects a commitment to delivering a product that not only meets but exceeds customer expectations.
For businesses and organizations looking to implement multiple units of the Advanced Water Level Sensor, bulk ordering options are available that offer more favorable pricing. This presents an excellent opportunity for companies to enhance their water management systems while benefiting from cost savings.
We encourage any interested parties to reach out for inquiries regarding bulk orders, as our team is ready to assist you in fulfilling your needs efficiently.
Contact us today for more information on how the Advanced Water Level Sensor can be integrated into your operations and to take advantage of our bulk pricing options.
| Material | Plastic |
|---|---|
| Product Attributes | Ordinary |
| Package Size | 180*230*40(mm) |
